Bone resorption
A cross section through the diaphysis of a long bone shows a resorption canal, the eroding tip of a remodeling unit. The process of bone remodeling forms a columnar-shaped channel in which bone is eroded at one tip by osteoclasts (forming a resorption canal) and is deposited at the other end by osteoblasts depositing the concentric lamellae of an osteon. 400x
![Resorption canal > <p>A cross section of a resorption canal can be identified by its irregular outline and lack of concentric lamellae. A resorption canal, like an Haversian canal, is lined by an endosteum, is filled with loose connective tissue and possesses a blood vessel(s). Active osteoclasts are present in the endosteum of a resorption canal, but would be absent in the endosteum of an Haversian canal.</p>](https://digitalhistology.org/wp-content/uploads/2018/02/T.C.B.D.11.P01.png)
Resorption canal >
A cross section of a resorption canal can be identified by its irregular outline and lack of concentric lamellae. A resorption canal, like an Haversian canal, is lined by an endosteum, is filled with loose connective tissue and possesses a blood vessel(s). Active osteoclasts are present in the endosteum of a resorption canal, but would be absent in the endosteum of an Haversian canal.
![- Osteoclasts <p>A cross section of a resorption canal can be identified by its irregular outline and lack of concentric lamellae. A resorption canal, like an Haversian canal, is lined by an endosteum, is filled with loose connective tissue and possesses a blood vessel(s). Active osteoclasts are present in the endosteum of a resorption canal, but would be absent in the endosteum of an Haversian canal.</p>](https://digitalhistology.org/wp-content/uploads/2018/02/T.C.B.D.11.P02.png)
- Osteoclasts
A cross section of a resorption canal can be identified by its irregular outline and lack of concentric lamellae. A resorption canal, like an Haversian canal, is lined by an endosteum, is filled with loose connective tissue and possesses a blood vessel(s). Active osteoclasts are present in the endosteum of a resorption canal, but would be absent in the endosteum of an Haversian canal.
![- Blood vessel <p>A cross section of a resorption canal can be identified by its irregular outline and lack of concentric lamellae. A resorption canal, like an Haversian canal, is lined by an endosteum, is filled with loose connective tissue and possesses a blood vessel(s). Active osteoclasts are present in the endosteum of a resorption canal, but would be absent in the endosteum of an Haversian canal.</p>](https://digitalhistology.org/wp-content/uploads/2018/02/T.C.B.D.11.P03.png)
- Blood vessel
A cross section of a resorption canal can be identified by its irregular outline and lack of concentric lamellae. A resorption canal, like an Haversian canal, is lined by an endosteum, is filled with loose connective tissue and possesses a blood vessel(s). Active osteoclasts are present in the endosteum of a resorption canal, but would be absent in the endosteum of an Haversian canal.
![Woven bone > <p>The bone in this image is classified as compact woven and lamellar bone</p>](https://digitalhistology.org/wp-content/uploads/2018/05/T.C.B.D.11.P04.png)
Woven bone >
The bone in this image is classified as compact woven and lamellar bone
![Lamellar bone <p>The bone in this image is classified as compact woven and lamellar bone</p>](https://digitalhistology.org/wp-content/uploads/2018/05/T.C.B.D.11.P05.png)
Lamellar bone
The bone in this image is classified as compact woven and lamellar bone
