Bone types: spongy and compact bone

Bone tissue is organized as spongy (cancellous) or compact (cortical) bone. Compact bone covers all exterior surfaces of a bone (except for the articular surfaces) and forms the majority of the shaft (diaphysis) of long bones, such as the femur. Spongy bone is located at the ends of the bone (epiphyses) and in the interior. 10X (top), 100x (bottom)

Spongy bone >  <p>Spongy bone, also called cancellous or trabecular bone, forms a honeycombed structure composed of interconnected, bony spicules. The spaces between the spicules are filled with red marrow. Spongy bone fills the epiphysis and is also present in the marrow cavity.</p>

Spongy bone >

Spongy bone, also called cancellous or trabecular bone, forms a honeycombed structure composed of interconnected, bony spicules. The spaces between the spicules are filled with red marrow. Spongy bone fills the epiphysis and is also present in the marrow cavity.

 - Spicules <p>Spongy bone, also called cancellous or trabecular bone, forms a honeycombed structure composed of interconnected, bony spicules. The spaces between the spicules are filled with red marrow. Spongy bone fills the epiphysis and is also present in the marrow cavity.</p>

- Spicules

Spongy bone, also called cancellous or trabecular bone, forms a honeycombed structure composed of interconnected, bony spicules. The spaces between the spicules are filled with red marrow. Spongy bone fills the epiphysis and is also present in the marrow cavity.

 - Red marrow <p>Spongy bone, also called cancellous or trabecular bone, forms a honeycombed structure composed of interconnected, bony spicules. The spaces between the spicules are filled with red marrow. Spongy bone fills the epiphysis and is also present in the marrow cavity.</p>

- Red marrow

Spongy bone, also called cancellous or trabecular bone, forms a honeycombed structure composed of interconnected, bony spicules. The spaces between the spicules are filled with red marrow. Spongy bone fills the epiphysis and is also present in the marrow cavity.

Compact bone >  <p>Compact bone, also called cortical bone, is present as a thin shell over the surface of the epiphyses as well as forming a solid mass, comprising the shaft (diaphysis) of long bones. </p>

Compact bone >

Compact bone, also called cortical bone, is present as a thin shell over the surface of the epiphyses as well as forming a solid mass, comprising the shaft (diaphysis) of long bones.

 - Epiphysis > <p>A thin shell of compact bone covers the surface of the epiphysis.</p>

- Epiphysis >

A thin shell of compact bone covers the surface of the epiphysis.

 - Diaphysis >  <p>Compact bone in the diaphysis can be organized either as flat, parallel sheets (lamellae), or in cylinders composed of concentric lamellae (Haversian systems).   </p>

- Diaphysis >

Compact bone in the diaphysis can be organized either as flat, parallel sheets (lamellae), or in cylinders composed of concentric lamellae (Haversian systems).

 -- Parallel lamellae> <p>Compact bone is deposited as flat, parallel sheets around the internal and external surfaces of the diaphysis, forming inner circumferential lamellae and outer circumferential lamellae, respectively.</p>

-- Parallel lamellae>

Compact bone is deposited as flat, parallel sheets around the internal and external surfaces of the diaphysis, forming inner circumferential lamellae and outer circumferential lamellae, respectively.

 -- Concentric lamellae <p>Compact bone on the interior of the diaphysis is organized in concentric lamellae forming Haversian systems. Haversian systems are oriented parallel to the long axis of the bone to provide strength and rigidity.</p>

-- Concentric lamellae

Compact bone on the interior of the diaphysis is organized in concentric lamellae forming Haversian systems. Haversian systems are oriented parallel to the long axis of the bone to provide strength and rigidity.

Image credit >  <p>This image was taken of slide in the University of Cincinnati collection.</p>

Image credit >

This image was taken of slide in the University of Cincinnati collection.
