Glomerulus
The pedicels of a podocyte contact the thick, combined basal laminae of the endothelial cell and the podocyte. The pedicels of one podocyte interdigitate with those from a different podocyte. In many cases, the connection of the pedicel with the primary process is not visible. The endothelium of the capillaries is widely fenestrated and lacks the diaphragms commonly seen in other fenestrated capillaries. 14,000x
Podocyte
The pedicels of a podocyte contact the thick, combined basal laminae of the endothelial cell and the podocyte. The pedicels of one podocyte interdigitate with those from a different podocyte. In many cases, the connection of the pedicel with the primary process is not visible. The endothelium of the capillaries is widely fenestrated and lacks the diaphragms commonly seen in other fenestrated capillaries. 14,000x
- Primary process
The pedicels of a podocyte contact the thick, combined basal laminae of the endothelial cell and the podocyte. The pedicels of one podocyte interdigitate with those from a different podocyte. In many cases, the connection of the pedicel with the primary process is not visible. The endothelium of the capillaries is widely fenestrated and lacks the diaphragms commonly seen in other fenestrated capillaries. 14,000x
- Pedicels
The pedicels of a podocyte contact the thick, combined basal laminae of the endothelial cell and the podocyte. The pedicels of one podocyte interdigitate with those from a different podocyte. In many cases, the connection of the pedicel with the primary process is not visible. The endothelium of the capillaries is widely fenestrated and lacks the diaphragms commonly seen in other fenestrated capillaries. 14,000x
Glomerular capillaries
The pedicels of a podocyte contact the thick, combined basal laminae of the endothelial cell and the podocyte. The pedicels of one podocyte interdigitate with those from a different podocyte. In many cases, the connection of the pedicel with the primary process is not visible. The endothelium of the capillaries is widely fenestrated and lacks the diaphragms commonly seen in other fenestrated capillaries. 14,000x
- Fenestrated endothelium
The pedicels of a podocyte contact the thick, combined basal laminae of the endothelial cell and the podocyte. The pedicels of one podocyte interdigitate with those from a different podocyte. In many cases, the connection of the pedicel with the primary process is not visible. The endothelium of the capillaries is widely fenestrated and lacks the diaphragms commonly seen in other fenestrated capillaries. 14,000x
Basal laminae
The pedicels of a podocyte contact the thick, combined basal laminae of the endothelial cell and the podocyte. The pedicels of one podocyte interdigitate with those from a different podocyte. In many cases, the connection of the pedicel with the primary process is not visible. The endothelium of the capillaries is widely fenestrated and lacks the diaphragms commonly seen in other fenestrated capillaries. 14,000x
Red blood cell
The pedicels of a podocyte contact the thick, combined basal laminae of the endothelial cell and the podocyte. The pedicels of one podocyte interdigitate with those from a different podocyte. In many cases, the connection of the pedicel with the primary process is not visible. The endothelium of the capillaries is widely fenestrated and lacks the diaphragms commonly seen in other fenestrated capillaries. 14,000x
Bowman’s space
The pedicels of a podocyte contact the thick, combined basal laminae of the endothelial cell and the podocyte. The pedicels of one podocyte interdigitate with those from a different podocyte. In many cases, the connection of the pedicel with the primary process is not visible. The endothelium of the capillaries is widely fenestrated and lacks the diaphragms commonly seen in other fenestrated capillaries. 14,000x
Area shown in next image
The pedicels of a podocyte contact the thick, combined basal laminae of the endothelial cell and the podocyte. The pedicels of one podocyte interdigitate with those from a different podocyte. In many cases, the connection of the pedicel with the primary process is not visible. The endothelium of the capillaries is widely fenestrated and lacks the diaphragms commonly seen in other fenestrated capillaries. 14,000x
