Overview

The external ear consists of an auricle or pinna, an S-shaped external acoustic meatus and the tympanic membrane or eardrum.

The auricle, or pinna (oval), with its framework of elastic cartilage, aids in accumulating sound waves. The external auditory meatus (arrows) is an S-shaped canal that terminates in the tympanic membrane (eardrum), separating the outer from the middle ear. Vibration of the tympanic membrane transmits sound vibrations to the ear ossicles.

The auricle, or pinna (oval), with its framework of elastic cartilage, aids in accumulating sound waves. The external auditory meatus (arrows) is an S-shaped canal that terminates in the tympanic membrane (eardrum), separating the outer from the middle ear. Vibration of the tympanic membrane transmits sound vibrations to the ear ossicles.

The middle ear, or tympanic cavity, is an air-filled space in the temporal bone. Three auditory ossicles span the cavity between the tympanic membrane and an opening in the wall of the inner ear, the oval window.

The auditory ossicles are three small bones spanning the tympanic cavity. The malleus (blue arrow) is attached to the tympanic membrane and articulates with the incus (red arrow). The incus is attached to the stapes (black arrow), whose foot plate fits into the oval window in the lateral wall of the inner ear. These ossicles transmit vibrations from the tympanic membrane to the inner ear.

The middle ear communicates with the mastoid air cells posteriorly (black arrows) and with the pharynx anteriorly through the auditory tube (Eustachian tube) (red arrows).

The inner ear is housed in the petrous portion of the temporal bone. This chamber consists of a complex series of cavernous, fluid-filled spaces, the osseous labyrinth (purple fill), from which are suspended a series of fluid-filled tubes and sacs, the membranous labyrinth (orange fill). Receptors in the tubes and sacs respond either to changes in sound or equilibrium.

The osseous labyrinth consists of a vestibule, three semicircular canals, and a cochlea, each filled with the fluid perilymph (purple fill). The vestibule (black arrow) is located centrally. Semicircular canals (only one shown here, blue arrow) extend posteriorly from the vestibule. The cochlea (shown straight here, red arrow) is a spiraling canal continuing anteromedially from the vestibule.

The membranous labyrinth is a series of ducts and sacs that are suspended in the osseous labyrinth and are filled with endolymph (orange fill). The utricle (black arrow) and saccule (green arrow) are suspended in the vestibule. A semicircular duct (red arrow) is suspended in each of the three semicircular canals. The cochlear duct (blue arrow) is suspended in the cochlea.

The endolymphatic duct begins as two ducts from the utricle and saccule in the vestibule and terminates in a sac-like ending between the meninges of the brain. Cells lining the duct presumably absorb endolymph and dispose of cellular debris that may be present in endolymph.

Cranial nerve VIII, the vestibulocochlear, innervates receptors located in each portion of the membranous labyrinth. These receptors respond to changes in either sound (receptors in cochlear duct) or position of the head (receptors in utricle, saccule and semicircular ducts).

Two openings connect inner and middle ears. The oval window (black arrow), in the lateral wall of the vestibule, is occupied by the foot plate of the stapes, where sound vibrations are transmitted to the perilymph. The round window (red arrow), located in the cochlea, is covered by a membrane that bulges into the middle ear, cushioning pressure created in the perilymph by movement of the stapes.

The ear, the organ of hearing and balance, is located in the temporal bone. The outer ear receives sound waves. The middle ear transmits sound waves through bone to the inner ear. The inner ear transduces these vibrations to nervous impulses for interpretation by the brain; it also maintains equilibrium. (Frontal view of left ear)
