Digital Histology
Main Menu » Organs & Systems » Cardiovascular » Vessels » Capillaries and Sinusoids » Capillaries and Sinusoids 16
This is blank.

Sinusoid

Endothelial cells that form sinusoids have large gaps (discontinuities) between adjacent endothelial cells as well as wide pores (fenestrations) in individual cells. These fenestrations do not have diaphragms. The basal lamina is discontinuous or absent. Shown here in the liver, these modifications allow for direct access of blood plasma to the space beneath the endothelium, into which hepatocytes project microvilli. 30,000x

Sinusoid lumens <p>Endothelial cells that form sinusoids have large gaps (discontinuities) between adjacent endothelial cells as well as wide pores (fenestrations) in individual cells. These fenestrations do not have diaphragms. The basal lamina is discontinuous or absent. Shown here in the liver, these modifications allow for direct access of blood plasma to the space beneath the endothelium, into which hepatocytes project microvilli. 30,000x</p>

Sinusoid lumens

Endothelial cells that form sinusoids have large gaps (discontinuities) between adjacent endothelial cells as well as wide pores (fenestrations) in individual cells. These fenestrations do not have diaphragms. The basal lamina is discontinuous or absent. Shown here in the liver, these modifications allow for direct access of blood plasma to the space beneath the endothelium, into which hepatocytes project microvilli. 30,000x
Endothelium <p>Endothelial cells that form sinusoids have large gaps (discontinuities) between adjacent endothelial cells as well as wide pores (fenestrations) in individual cells. These fenestrations do not have diaphragms. The basal lamina is discontinuous or absent. Shown here in the liver, these modifications allow for direct access of blood plasma to the space beneath the endothelium, into which hepatocytes project microvilli. 30,000x</p>

Endothelium

Endothelial cells that form sinusoids have large gaps (discontinuities) between adjacent endothelial cells as well as wide pores (fenestrations) in individual cells. These fenestrations do not have diaphragms. The basal lamina is discontinuous or absent. Shown here in the liver, these modifications allow for direct access of blood plasma to the space beneath the endothelium, into which hepatocytes project microvilli. 30,000x
- Gaps and fenestrations <p>Endothelial cells that form sinusoids have large gaps (discontinuities) between adjacent endothelial cells as well as wide pores (fenestrations) in individual cells. These fenestrations do not have diaphragms. The basal lamina is discontinuous or absent. Shown here in the liver, these modifications allow for direct access of blood plasma to the space beneath the endothelium, into which hepatocytes project microvilli. 30,000x</p>

- Gaps and fenestrations

Endothelial cells that form sinusoids have large gaps (discontinuities) between adjacent endothelial cells as well as wide pores (fenestrations) in individual cells. These fenestrations do not have diaphragms. The basal lamina is discontinuous or absent. Shown here in the liver, these modifications allow for direct access of blood plasma to the space beneath the endothelium, into which hepatocytes project microvilli. 30,000x
Hepatocytes <p>Endothelial cells that form sinusoids have large gaps (discontinuities) between adjacent endothelial cells as well as wide pores (fenestrations) in individual cells. These fenestrations do not have diaphragms. The basal lamina is discontinuous or absent. Shown here in the liver, these modifications allow for direct access of blood plasma to the space beneath the endothelium, into which hepatocytes project microvilli. 30,000x</p>

Hepatocytes

Endothelial cells that form sinusoids have large gaps (discontinuities) between adjacent endothelial cells as well as wide pores (fenestrations) in individual cells. These fenestrations do not have diaphragms. The basal lamina is discontinuous or absent. Shown here in the liver, these modifications allow for direct access of blood plasma to the space beneath the endothelium, into which hepatocytes project microvilli. 30,000x
- Hepatocyte microvilli <p>Endothelial cells that form sinusoids have large gaps (discontinuities) between adjacent endothelial cells as well as wide pores (fenestrations) in individual cells. These fenestrations do not have diaphragms. The basal lamina is discontinuous or absent. Shown here in the liver, these modifications allow for direct access of blood plasma to the space beneath the endothelium, into which hepatocytes project microvilli. 30,000x</p>

- Hepatocyte microvilli

Endothelial cells that form sinusoids have large gaps (discontinuities) between adjacent endothelial cells as well as wide pores (fenestrations) in individual cells. These fenestrations do not have diaphragms. The basal lamina is discontinuous or absent. Shown here in the liver, these modifications allow for direct access of blood plasma to the space beneath the endothelium, into which hepatocytes project microvilli. 30,000x
- Glycogen <p>Endothelial cells that form sinusoids have large gaps (discontinuities) between adjacent endothelial cells as well as wide pores (fenestrations) in individual cells. These fenestrations do not have diaphragms. The basal lamina is discontinuous or absent. Shown here in the liver, these modifications allow for direct access of blood plasma to the space beneath the endothelium, into which hepatocytes project microvilli. 30,000x</p>

- Glycogen

Endothelial cells that form sinusoids have large gaps (discontinuities) between adjacent endothelial cells as well as wide pores (fenestrations) in individual cells. These fenestrations do not have diaphragms. The basal lamina is discontinuous or absent. Shown here in the liver, these modifications allow for direct access of blood plasma to the space beneath the endothelium, into which hepatocytes project microvilli. 30,000x
- Mitochondria <p>Endothelial cells that form sinusoids have large gaps (discontinuities) between adjacent endothelial cells as well as wide pores (fenestrations) in individual cells. These fenestrations do not have diaphragms. The basal lamina is discontinuous or absent. Shown here in the liver, these modifications allow for direct access of blood plasma to the space beneath the endothelium, into which hepatocytes project microvilli. 30,000x</p>

- Mitochondria

Endothelial cells that form sinusoids have large gaps (discontinuities) between adjacent endothelial cells as well as wide pores (fenestrations) in individual cells. These fenestrations do not have diaphragms. The basal lamina is discontinuous or absent. Shown here in the liver, these modifications allow for direct access of blood plasma to the space beneath the endothelium, into which hepatocytes project microvilli. 30,000x
Main SlideSinusoid lumensEndothelium - Gaps and fenestrationsHepatocytes - Hepatocyte microvilli - Glycogen - Mitochondria
